75C - L Slurry Pump for High Efficient Energy Conservation Placer Mining Equipment

  • >=1 Sets
    $1,550.00
Type:
SEWAGE PUMPS Effluent Pumps Grinder Pumps Dewatering Pumps Trash Pumps Self-Priming Sewage & Trash Pumps Centrifugal Pumps Booster Pumps WELL PUMPS Circulating Pumps Turbine Pumps Positive displacement pumps Jet Pumps CHEMICAL PUMPS Drum & Barrel Pumps Fuel & Oil Transfer Pumps HVAC Condensate Removal Pumps Fountain & Pond Pumps Pool & Tub Pumps Marine & RV Pumps
Maximum Head:
45 M
Maximum Flow Rate:
150 M3/HR
Shipping:
Support Sea freight · Land freight · Air freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 5 Sets)
Customized packaging (Min. Order: 5 Sets)

More

Graphic customization (Min. Order: 5 Sets) Less
Samples:
$1,550.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Brand Name:
NP
Model Number:
75C-L
Place of Origin:
Hebei, China
Application:
Industrial Utilities, Irrigation and Agriculture, Machining, Marine, Metal and Equipment Manufacturers, Mining industry, Pharmaceutical industry, Raw Water Intake, Washing and Cleaning, Wastewater Transport and Flood Control, wastewater treatment, Water Distribution, Water Treatment Solutions, Coal Washing, Chemical Medium Processing, Effluent Handling
Horsepower:
40
Power Source:
Electric, Diesel
Pressure:
Low pressure
Structure:
Single-stage Pump
Outlet Size:
75mm
Voltage:
380v, 400v, 440v, 480v...
Power:
30
Certification:
ce
Usage:
Water
Theory:
Centrifugal Pump
OEM:
Accepted
Non-standard:
Available
Material:
NR55, PU, A05, A33, A49, A61...
Impeller:
Open
Warranty:
1 Year(except Wearing Parts)
Feature:
Corrosion Resistant
Type:
Horizontal mining pump
Supply Ability
Supply Ability:
500 Set/Sets per Month 43056 Impeller pump
Packaging & Delivery
Packaging Details
Standard export wooden cases or according to the pumps and customer's request
Port
Xingang, Tianjin
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Video Description

75C-L Slurry Pump for High Efficient Energy Conservation Placer Mining Equipment

Product Description

L(R) mining slurry pump



L(R) -Series slurry pumps are widely used in mining , power, metallurgy, coal, dredging, building material and other industrial lines to pump concentrate, tailing, sludge, and other abrasive high density slurries.



2.1 There are two types of material for wet parts (volute liners, front and back liners, impellers):
l Made of high-chrome alloy material;
l Made of highly wear-resistant rubber material researched and developed by Naipu company.

2.2 Structure of shaft seals:
l Packing gland seals;
l Pressure-reducing metal gland seals;
l Pressure-reducing rubber gland seals;
l Mechanical seals.

Pump Parameters

L(R) slurry pump selection chart

( Note: Approximate performance for clear water,to be used for primary selection only.)

Low Abrasive Slurry Pump performance parameters

Type

Max.

Power

Kw

Clear Water Performance

Impeller

Application



Capacity

m³/hr

Head/m

Speed/rpm

Efficiency

%

NPSH

m

Nos

of

Vane

Diameter

mm

20A-L

7.5

2.34-10.8

6-37

1400-3000

30

3.5-8

4

152.4

-Ball mill discharge

50B-L

15

16.2-76

9-44

1400-2800

55

3.5-8

5

190

-Coarse tailings

75C-L

30

18-151

4-45

900-2400

57

3-6

4

229

-Rod mill discharge

100D-L

60

50-252

7-46

800-1800

60

2-3.5

4

305

-Coal washing

150E-L

120

115-486

12-51.5

800-1500

65

2-6

4

381

-Wet crushers

200E-L

120

234-910

9.5-40

600-1100

64

3-6

4

457

-Phosphate matrix

250F-L

120

396-1425

8-30

500-800

77

2-10

5

550

-Minerals concentrate

300S-L

560

468-2538

8-60

400-950

79

2-10

5

653

-Lime grinding

350S-L

560

650-2800

10-59

400-840

81

3-10

5

736

-FGD waste water

400ST-L

560

720-3312

7-51

300-700

80

2-10

5

825

-Flotation

450ST-L

560

1008-4356

9-48

300-600

80

2-9

5

933

-Process chemical

550TU-L

1200

1980-7900

10-50

250-475

86

4-10

5

1213

-Pulp and paper

20A-LR

7.5

2.16-9

7-32

1600-3000

30



3

152.4

-Ni acid slurry

50B-LR

15

12.6-60

6-38

1200-2600

48



3

190

-Coarse sand

75C-LR

30

22-144

9-43

1000-2200

60

3-5

4

229

-Heavy media

100D-LR

60

61-252

17-70

800-1600

65

2-5

6

305

-Bottom/fly ash

150E-LR

120

137-486

12-51.5

800-1300

65

2.5-5.5

5

381

-Oil sands

200E-LR

120

216-990

9.5-40

500-1100

74



5

457

-Mineral sands

250F-LR

260

324-1314

8-30

500-800

70

5--10

5

550

-Fine tailings

300S-LR

560

432-1900

7-41

400-800

81

3-8

5

653

-Phosphoric acid

350S-LR

560

720-2844

10-41

400-700

86

3-7

5

736

-Coal

400ST-LR

560

756-3312

7-37.5

300-600

85

2-8

5

825



450ST-LR

560

1080-4356

9-40

300-550

87

3-10

5

933



650U-LR

2000

2520-9108

10-39

200-350

86

2-8

5

1370



750UV-LR

2000

3240-13860

8-41

150-300

86

2-8

5

1643


Product Construction

1. Slurry pump construction drawing

75CL Slurry Pump Main part number at the drawing

032: Frame Plate
060: Intake Joint
132: Discharge Joint
083: Throatbush
110: Volute Liner
147: Impeller
122: Stuffing Box Seal
036: Frame Plate Liner
013: Cover Plate
018: Cover Plate Liner
124: Volute Liner Seal
041: Frame Plate Liner Insert



Related Products

Naipu pump produce many kinds of centrifugal slurry pump for mining, sand and other solids slurry transporting.



HA Rubber Lined Slurry Pump Cover Plate Liner of Slurry Pump
14 inches High Head Sand Dredging Pump 18x16 Sand Slurry Pump

FAQ



Q1. How slurry pump works?

   A: HA(R) slurry pumps are those of cantilever, horizontal and centrifugal ones, which are widely used to transport corrosive/ abrasive and high concentration slurry in many industries.



Q2. How to gurantee the quality?

  A:  All our pump and spare parts pass ISO 9001:2008 and CE certificate.   Warranty time is 12 month except wet end parts.



Q3. What information should be known if I want to get a quotation?

   A: Pump working conditions, Usage , Pump Capacity, pump Head , Slurry SG, The More the Better. Please offer me the type of the used pump that working now.



Q4. Manaufacturer or trader?

  A: Manufacturer of couse. Our Factory located in Shijiazhuang , Hebei , China . Welcome to visit.



Q5. Your company product range?

  A: Centrifugal pump, Slurry pump, Sand pump, Gravel pump, Dredging pump, Clean water pump, Sewage pump, Chemical pump, Single stage pump, Double suction pump, Industry pump, Paper pulp pump, Mud pump, Sludge pump, etc



Q6. Delivery time:

 A: For the Common Slurry pump and spare parts , the delivery time within 7-15 days. Special material and OEM production is longer.



Contact Katherine

Contact Persion: Katherine Hou

Cellphone/ WeChat/ WhatsApp: +86-15028111051 Skype: katherine_naipump
Email: katherine at naipump dot com

Company Information

Shijiazhuang Naipu Pump Co., Ltd is a professional manufacturing enterprise of slurry pumps and spare parts. Which own Mould Workshop, Casting Workshp, Machining Workshop and Assembly Workshop.



Various requirement for materials in the market, Naipu offering wet end part material as following. Metal A05, A07, A12, A33, A49, A61 and etc. Rubber R08, R26, R33, NR55, S01, S21, S31, S42 and etc. Special materail: U01, EPDM, PU, CR, Hastelloy 276-C, Ferralium and etc.

Given customer's special request for abrasion and erosion in pumping environments, we can supply the material according to customer's material formula or sample to meet your need.

Naipu is willing to undertake any OEM(Original Equipment Manufacture) order for pump and mining equipment accoring to the drawing or sample.
